Poynting EPNT-4 Antenna Unit with Enclosure 4x4 LTE (MIMO), 2x2 Wi-Fi (MIMO)

Description

X-Polarised, Omni-Directional LTE/5G & Wi-Fi Antenna; 617 - 4200 MHz; 4x4 LTE (MIMO), 2x2 Wi-Fi (MIMO), GPS/GLONASS

The Poynting EPNT-4 Antenna Enclosure allows you to integrate your 4×4 Router within this enclosure. With the 4×4 omni-directional antenna that is also housed in the enclosure you reduce cable losses and improve performance significantly.

Poynting is proud to introduce this self-contained omni-directional LTE/5G enclosure that integrates both antenna and the customers 4×4 router within a stylish outdoor enclosure. The enclosure can accommodate routers up to the size of 140 mm x 120 mm x 50 mm which results in negligible cable losses between the antennas and the router.

Features

• Reduced cable losses.
• Higher throughput.
• A cleaner Installation.
• 4×4 MIMO for improved equipment performance/throughput
• Exceptional performance across the whole band, excellent for carrier aggregation
• Futureproof 5G antenna enclosure ideal for FWA installations
• Ultra-wideband as it covers 617 to 7200 MHz. This includes: LTE/5G bands from 617 to 4200 MHz, Band 71 from 617 to 698 MHz, CBRS Band from 3.5 to 4.2 GHz, Dual-Band Wi-Fi antennas for 2.4 GHz and 5 to 7.2 GHz

Where to use it?

• Designed for commercial, industrial, residential, and urban applications, where reliable LTE/5G reception is required
• Ideal for Fixed Wireless Access (FWA) where an outdoor antenna is required for housing CPE electronics in one easy deploy solution
• Marine applications, such as ferries, private yachts, and towing vessels.
• Smart Environmental, Water Systems and Utilities M2M & IoT
• Farming & Agricultural M2M & IoT
• Oil & Gas communication systems
• Municipal & Government systems
• Other applications with harsh environments such as harbour buildings, buoys, pontoons, and smaller boats
